MODEL |
J1900 |
I5 |
Processor |
Intel BayTrail J1900 2.0 GHZ (Quad Core) |
Intel Celeron/Pentium/CoreTM I3/I5/I7 processor |
Chipset |
Intel BayTrail - D |
Intel Nm70 Express |
Memory (RAM) |
4GB DDR3 SODIMM to 8GB (1333/1666 MHz) |
4GB DDR3 SODIMM to 8GB (1333/1666 MHz) |
Graphics Memory |
Intel HD Graphics E3800 Core |
Intel HD Graphics 520 |
Flash Disk |
120 GB SSD HDD 2.5’’ /MSATA |
120 GB SSD HDD 2.5’’ /MSATA |
HDD (option) |
1 x HDD 2.5’’ (rack mounted) |
1 x HDD 2.5’’ (rack mounted) |
Touch Panel |
17“ LED LCD projected Capacitive panel |
17“ LED LCD projected Capacitive panel |
Resolution |
1280 x 1024 |
1280 x 1024 |
INPUTS/ OUTPUTS | ||
VGA |
1 |
1 |
Power Button |
1 |
1 |
USB |
4 x USB 2.0 + 2 x USB 3.0 |
6 x USB 3.0 |
Serial/COM |
2 x RS-232 1 x LPT(option) |
2 x RS-232 1 x LPT(option) |
LAN |
1 LAN 10/100/1000 |
1 LAN 10/100/1000 |
Para Çekmecesi |
1 x RJ 11 (12V / 24V) Option |
1 x RJ 11 (12V / 24V) Option |
Display Port |
1 (for 2nd screen) |
1 (for 2nd screen) |
HDMI |
1 |
1 |
DRIVERS | ||
Customer Display |
Graphic customer display (high readability) - (option) | |
Mini PC port |
Integrated | |
Power supply |
Adapter 12V / 4-7A | |
Dimensions (W x H x D) |
387 x 410 x 200mm / (working position tilted at 45°) | |
Net Weight |
4.4 kg / (not including power supply or customer display) | |
Materials |
High Quality Case, Aluminum Casting & Plastic | |
Colors |
3 modul colours (Black-Red-White) | |
Comptatible OS |
Windows 7, Windows 8.1, Windows10, Posready 7 |
OPTIONAL ACCESSORIES | ||
Graphical customer display (high readability) | ||
Card reader | ||
10.1 '' Back screen Support (high Resolution) |
