Product code

L009UiGS-RM

Architecture

ARM

CPU

IPQ-5018

CPU core count

2

CPU nominal frequency

800 MHz

Switch chip model

88E6190

RouterOS license

5

Operating System

RouterOS v7

Size of RAM

512 MB

Storage size

128 MB

Storage type

NAND

MTBF

Approximately 200'000 hours at 25C

Tested ambient temperature

-40°C to 70°C

Suggested price

$119.00

Number of DC inputs

2 (DC jack, PoE-IN)

DC jack input Voltage

24-56 V

Max power consumption

40 W

Max power consumption without attachments

8 W

Cooling type

Passive

PoE in

802.3af/at

PoE in input Voltage

24-56 V

PoE-out ports

Ether8

PoE out

Passive PoE

Max out per port output (input 18-30 V)

1 A

Max out per port output (input 30-57 V)

450 mA

Max total out (A)

1 A

10/100/1000 Ethernet ports

8

Number of 1G Ethernet ports with PoE-out

1

SFP ports

1 (2.5G supported)

Serial console port

RJ45

Number of USB ports

1

USB Power Reset

Yes

USB slot type

USB 3.0 type A

Max USB current (A)

1.5

Mode button

Yes

Certification

CE, EAC, ROHS

IP

20
