MODEL

I5

Processor

Intel Celeron/Pentium/CoreTM I5 processor

Chipset

Intel Nm70 Express

Memory (RAM)

4GB DDR3 SODIMM to 8GB (1333/1666 MHz)

Graphics Memory

Intel HD Graphics 520

Flash Disk

120 GB SSD HDD 2.5’’ /MSATA

HDD (option)

1 x HDD 2.5’’ (rack mounted)

Touch Panel

17“ LED LCD projected Capacitive panel

Resolution

1280 x 1024

INPUTS/ OUTPUTS

VGA

1

Power Button

1

USB

6 x USB 3.0

Serial/COM

2 x RS-232 1 x LPT(option)

LAN

1 LAN 10/100/1000

Para Çekmecesi

1 x RJ 11 (12V / 24V) Option

Display Port

1 (for 2nd screen)

HDMI

1

DRIVERS

Customer Display

Graphic customer display (high readability) - (option)

Mini PC port

Integrated

Power supply

Adapter 12V / 4-7A

Dimensions (W x H x D)

387 x 410 x 200mm / (working position tilted at 45°)

Net Weight

4.4 kg / (not including power supply or customer display)

Materials

High Quality Case, Aluminum Casting & Plastic

Colors

3 modul colours (Black-Red-White)

Comptatible OS

Windows 7, Windows 8.1, Windows10, Posready 7

OPTIONAL ACCESSORIES

Graphical customer display (high readability)

Card reader

10.1 '' Back screen Support (high Resolution)
