SPECIFICATIONS

PHYSICAL CHARACTERISTICS

Dimension

170mm(H)x79mm(W)x15mm(D)

Display

5.99inch. HD+ 1400*720 IPS Screen

Side Key

Power key (lock screen key) + scan key + volume increase + volume decrease

Backlight

LED backlight

Expansions

2SIM,1TF, (TF-card can up to 32GB ROM)

Battery

Rechargeable li-ion polymer, 4.3V, 4000mAh

speaker

1W/8R

Sensor

G- Sensor,Light Distance Sensor,Fingerprint

Scanner

1D&2D barcode scanner engine

Barcode type

1D: UPC-A, upc-e, upc-e1, EAN-13, ean-8, ISBN/ ISSN, 39, 39 (full code),code32

trioptic39, cross 25, industry 25, matrix 25, kudeba (NW7), 128, ISBT128,code93

code11, MSI/ Plessey, UK/ Plessey, UCC/ EAN128 (gs1-128),China Post code,

China finance code, gs 1 databar (formerly RSS) series

2D: PDF41 7, MicroPDF41 7, QR code, micro qr code, DataMatrix, Hanxin code,

Aztec code, GS1 composite

Camera

8 megapixel camera auto-focus with LED flash+2 megapixel front camera

Port

USB Type C

PERFORMANCE CHARACTERSTICS

CPU

Cortex-a53 4-core, 1 .5GHz

Operating System

Android 8.1

Storage

2GB RAM+16GB ROM

USER ENVIRONMENT

Operating Temp.

-0℃ to 45℃

Storage Temp.

-20℃ to 70℃

Humidity

5%RH to 95%RH(non-condensing)

DEVELOPMENT ENVIRONMENT

SDK

HHW Software Development Kit

Language

Java

Environment

Android Studio or Eclipse

DATA COMMUNICATION

WWAN

GSM/GPRS/WCDMA/TD_ SCDMA/TDD_ _LTE/FDD-LTE

WCDMA

WCDMA B1(2100)MHZ B5(850)MHz B8(900)MHz

GSM

850/900/1800/1900

TDSCDMA

B34,B39

TDD-LTE

B38,B39,B41,B42

FDD-LET

B1,B3,B5,B7,B20

WLAN

IEEE 802.11 a/b/g/n2.4GHz&5GHz

Bluetooth

Bluetooth v2.1,V3.0,V4.0+BLE

GPS

GPS&AGPS

NFC

14443A,14443B
