Main Processor |
Industrial-grade embedded processor | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
OS |
Embedded Linux | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operation Interface |
Web/operating in local GUI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection by Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
8 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Search |
Search for pictures by channel, time and event type | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection by Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
4 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Attributes |
6 attributes: Gender, age, glasses, expression, mouth mask, and beard | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Search |
Search for pictures by channel, time and face attributes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus by Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
8 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Search |
Search by target classification (human, vehicle) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Access Channel |
8 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Bandwidth |
Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capability |
8 × 1080p@30 fps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Output |
1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-screen Display |
1, 4, 8, 9 views | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Third-party Camera Access |
ONVIF; RTSP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
Smart H.265/H.265/Smart H.264/H.264/MJPEG | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio |
PCM/G711A/G711U/G726/AAC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone Access |
Android; iOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF(profile T/S/G); CGI; SDK | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser |
Chrome; IE9 or later; firefox | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Playback | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-channel Playback |
Up to 8 channels for playback | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Mode |
Manual record; alarm recording; SMD recording; smart recording | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
Local HDD; network | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backup |
USB storage device |
|
1. Play/pause/stop/slow/quick/backward/by frame | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Disk Group |
Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Alarm |
Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Anomaly Alarm |
Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligent Alarm |
Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Linkage |
Recording, snapshot, audio, buzzer, log, preset, and email | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
External Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
1 × RCA input | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output |
1 × RCA output | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDD |
1 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB |
2 (2 × back USB2.0) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDMI |
1 (supports up to 4K resolution output) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VGA |
1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
POE |
8 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
DC48V/53V, 2A/1.8A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
< 10 W (HDD not included, idling) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
0.70 kg (1.54 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
1.80 kg (3.97 lb | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions |
270 mm × 206.5 mm × 47.5 mm (10.63" × 8.13" × 1.87") (W × L × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Package Dimensions |
96 mm × 427 mm × 262 mm (3.78" × 16.81" × 10.31") (W × L × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Conditions |
–10 °C to +50 °C (+10 °F to +122 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Conditions |
0 °C to +40 °C (32 °F to 104 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
10℅~93℅ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity |
30%~85% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Altitude |
3000 m (9842.52 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation |
Desktop mounted | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4 |
