RMS/AES power handling: 2 x 480 W

Frequency: Response (± 3 dB): 50 Hz - 22 kHz

Signal / Noise: > 100 dB

THD+N (@ 1 kHz):

Crosstalk (@ 1 kHz):

Technology: Class-D

Power: Supply: Switching mode

Source: 230 ~ 240 V AC / 50 Hz

Inputs: Sensitivity: -0.5 dB ~ 10.5 dB

Impedance: 10 kΩ balanced

Connector: XLR female with Male Linkthrough

Outputs: Voltage / Impedance: 100 V / 21 Ω

Connector: 4-pin Euro Terminal Block (Pitch - 5.08 mm)

Common mode rejection ratio: 70 dB

Protection: DC Short circuit

Over heating

Over load

Signal limiting

Cooling: Temperature controlled fan

Operating temperature: 0° ~ 40° @ 95% Humidity

Product Features

Dimensions: 482 x 88 x 420 mm (W x H x D)

Weight: 7.500 kg

Mounting: 19”

Unit height: 2 HE

Construction: Steel

Colours: Black

Accessories: Included: 2 x 4-pin Euro Terminal Block outputs connector

Optional: CPE100 Rack mount handles
