Product code

RB912R-2nD-LTm&R11e-LTE

Architecture

MIPSBE

CPU

QCA9531

CPU core count

1

CPU nominal frequency

650 MHz

Dimensions

139 x 77 x 28,5 mm

RouterOS license

4

Operating System

RouterOS

Size of RAM

64 MB

Storage size

16 MB

Storage type

FLASH

MTBF

Approximately 200'000 hours at 25C

Tested ambient temperature

-40°C to 50°C

Suggested price

$149.00

MicroUSB input Voltage

5-5 V

Number of DC inputs

3 (DC jack, PoE-IN, MicroUSB)

DC jack input Voltage

8-30 V

Max power consumption

9 W

Cooling type

Passive

PoE in

802.3af/at

PoE in input Voltage

12-57 V

2G Category

Class12

2G bands

2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)

3G Category

R7 (21Mbps Downlinks, 5.76Mbps Uplink)

3G bands

1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz)

LTE Category

4 (150Mbps Downlink, 50Mbps Uplink)

LTE FDD bands

1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz)

LTE TDD bands

38 (2600MHz) / 40 (2300MHz)

TAC

35565409

Wireless 2.4 GHz Max data rate

300 Mbit/s

Wireless 2.4 GHz number of chains

2

Wireless 2.4 GHz standards

802.11b/g/n

Antenna gain dBi for 2.4 GHz

1.5

Wireless 2.4 GHz chip model

QCA9531

Wireless 2.4 GHz generation

Wi-Fi 4

10/100 Ethernet ports

1

Number of SIM slots

2 Modem (Mini SIM)

MiniPCI-e slots

1

Serial console port

RS232

Number of USB ports

1

USB Power Reset

Yes

USB slot type

microUSB type AB

Max USB current (A)

1

Mode button

Yes

GNSS standards

GPS

GPS RF connector type

uUFL

Certification

CE, FCC, IC, E-MARK, EAC, ROHS

IP

IP54

1MBit/s

22

-96

11MBit/s

22

-89

6MBit/s

20

-93

54MBit/s

18

-74

MCS0

20

-93

MCS7

16

-71
