System | Main Processor | Hi3520DV300 |
Operation System | LINUX, Compression Mode: H.265 | |
Video | Video Input | 4CH BNC |
Video Output | 1 x VGA / 1 x HDMI (1920*1080) | |
Video Distance | 75-3 Cable up to 500 Meters / Video No Decay and Distortion | |
Audio | Audio Input | 1CH RCA |
Audio Output | 1CH RCA | |
Recording | Recording Channel | 4CH ×5M-N@20fps |
Reolution | 5M-N | |
Recording Mode | Realtime Video Recording | |
Playback | Playback Channel | 2CH x 5M-N@12fps/4CH × 1080P@12fps |
Playback Mode | Normal Play, Fast Forward, Frame by Frame, Zoom In / Out | |
Search Mode | Time, Date, Motion Detection, Exact Search | |
Alarm | Alarm Input | N/A |
Alarm Output | N/A | |
Storage | HDD Interface | 1 x SATA Fixed HDD |
Capability | SATA HDD up to 6TB each | |
Backup | USB Disk | 2 x USB 2.0 port |
Backup Format | H.265 (only for Playback Software - General H.265 Player V1.7.0.) | |
Backup Mode | Network download / Flash USB / movable HDD/SATA HDD / DVD-RW | |
PTZ | PTZ | R485 control |
Network | Interface | RJ45 port / 10M / 100M / 1,000Mbps Ethernet |
Protocol | TCP/IP, DHCP, DDNS, PPPoE, UPNP, NTP, SMTP, FTP, RTSP, ARSP | |
Mobile phone Support | mobile view app XMeye (iPhone, Android) | |
Computer System Support | iCloud Software, one-click online;Windows 2000, XP, Vista, 7, 8 / Mac OS x 10.6/10.7 | |
Compatible Browser | Support IE, Firefox, Google Chrome,28 kinds of Languages | |
Free DDNS | iCloud Free DDNS Server (P2P function) | |
IP Camera Protocol | ONVIF Version Platform Protocol (Digital Menu) | |
Simultaneous Remote Viewers | 6 Users Online | |
Others | Operating Temperature | 0°C ~ 55°C |
Operating Humidity | 10% ~ 90% | |
Dimension | 255mm×230mm×45mm | |
Weight | 2 KG/ (2 SATA 2.5KG) | |
HDD Screw | 4 PCS (1 Pack) | |
Accessories | USB Mouse ×1PC/User Manual ×1PC/Remote Controller × 1PCPower Supply × 1PC | |
Power Supply | DC12V/2A |
