Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor |
1/3” 4Megapixel progressive CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution |
2688 (H) × 1520 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM |
128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM |
128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System |
Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio |
> 56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination |
0.008 Lux@F1.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance |
30 m (98.43 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control |
Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number |
1 (IR LED) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range |
Pan: 0°–360° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type |
Fixed-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type |
M12 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length |
2.8 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture |
F1.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View |
2.8 mm: 3.6 mm : | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Type |
Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance |
2.8 mm: 0.9 m (2.95 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
2.8 mm |
56 m (183.73 ft) |
22.4 m (73.49 ft) |
11.2 m (36.75 ft) |
5.6 m (18.37 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
3.6 mm |
80 m (262.47 ft) |
32.0 m (104.99 ft) |
16.0 m (52.49 ft) |
8.0 m (26.25 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart event | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS |
Tripwire; intrusion | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression |
H.265; H.264; H.264B; MJPEG(only supported by sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec |
Smart H.265+/ Smart H.264+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate |
Main stream: 2688 × 1520 (1 fps-20 fps) 2560 × 1440 (1 fps-25/30 fps) Sub stream: 704 × 576 (1 fps-25 fps) 704 × 480 (1 fps-30 fps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability |
2 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control |
CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate |
H.264: 32 kbps–6144 kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night |
Auto(ICR)/Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC |
Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC |
Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR |
120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control |
Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction |
3D NR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection |
OFF/ON (4 areas, rectangular) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest(RoI) |
Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Illumination |
Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation |
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror |
Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking |
4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; voltage detection; security exception | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SDK and API |
Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host |
20 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
FTP; SFTP; Micro SD Card (support max. 256 GB); NAS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser |
IE | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software |
Smart PSS; DSS; DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone |
IOS; Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE-LVD: EN62368-1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
12V DC/PoE (802.3af) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
< 5W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Conditions |
-40°C to +60°C (-40°F to +140°F)/less than ≤ 95% RH | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Strorage Conditions |
-40°C to +60°C (-40°F to +140°F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection |
IP67 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing |
Metal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
166.2 mm × Φ70 mm (6.54" × Φ2.76") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
0.48 kg (1.1 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
0.57 kg (1.3 lb) |
