Specifications
|
Details | |
|
Product code |
RB760iGS |
|
Architecture |
MMIPS |
|
CPU |
MT7621A |
|
CPU core count |
2 |
|
CPU nominal frequency |
880 MHz |
|
CPU Threads count |
4 |
|
Switch chip model |
MT7621A |
|
Dimensions |
113 x 89 x 28 mm |
|
RouterOS license |
4 |
|
Operating System |
|
|
Size of RAM |
256 MB |
|
Storage size |
16 MB |
|
Storage type |
FLASH |
|
MTBF |
Approximately 100'000 hours at 25C |
|
Tested ambient temperature |
-40°C to 70°C |
|
IPsec hardware acceleration |
Yes |
|
Suggested price |
$79.00 |
Powering
|
Details | |
|
Number of DC inputs |
2 (DC jack, PoE-IN) |
|
DC jack input Voltage |
12-57 V |
|
Max power consumption |
24 W |
|
Max power consumption without attachments |
6 W |
|
Cooling type |
Passive |
|
PoE in |
802.3af/at |
|
PoE in input Voltage |
12-57 V |
PoE-out
|
Details | |
|
PoE-out ports |
Ether5 |
|
PoE out |
Passive PoE up to 57V |
|
Max out per port output (input 18-30 V) |
500 mA |
|
Max out per port output (input 30-57 V) |
500 mA |
|
Max total out (A) |
500 mA |
Ethernet
|
Details | |
|
10/100/1000 Ethernet ports |
5 |
Fiber
|
Details | |
|
SFP ports |
1 |
Peripherals
|
Details | |
|
Memory card type |
microSD |
|
Memory Cards |
1 |
|
Number of USB ports |
1 |
|
USB Power Reset |
Yes |
|
USB slot type |
USB type A |
|
Max USB current (A) |
1 |
Other
|
Details | |
|
PCB temperature monitor |
Yes |
|
Voltage Monitor |
Yes |
|
Mode button |
Yes |
|
Beeper |
Yes |
Certification & Approvals
|
Details | |
|
Certification |
CE, EAC, ROHS |
|
IP |
IP20 |
