Details | |
Product code |
RB760iGS |
Architecture |
MMIPS |
CPU |
MT7621A |
CPU core count |
2 |
CPU nominal frequency |
880 MHz |
CPU Threads count |
4 |
Switch chip model |
MT7621A |
Dimensions |
113 x 89 x 28 mm |
RouterOS license |
4 |
Operating System |
|
Size of RAM |
256 MB |
Storage size |
16 MB |
Storage type |
FLASH |
MTBF |
Approximately 100'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
IPsec hardware acceleration |
Yes |
Suggested price |
$79.00 |
Details | |
Number of DC inputs |
2 (DC jack, PoE-IN) |
DC jack input Voltage |
12-57 V |
Max power consumption |
24 W |
Max power consumption without attachments |
6 W |
Cooling type |
Passive |
PoE in |
802.3af/at |
PoE in input Voltage |
12-57 V |
Details | |
PoE-out ports |
Ether5 |
PoE out |
Passive PoE up to 57V |
Max out per port output (input 18-30 V) |
500 mA |
Max out per port output (input 30-57 V) |
500 mA |
Max total out (A) |
500 mA |
Details | |
10/100/1000 Ethernet ports |
5 |
Details | |
SFP ports |
1 |
Details | |
Memory card type |
microSD |
Memory Cards |
1 |
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB type A |
Max USB current (A) |
1 |
Details | |
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Mode button |
Yes |
Beeper |
Yes |
Details | |
Certification |
CE, EAC, ROHS |
IP |
IP20 |
