- Touch to exit

- Output Contact: NO\NC\COM

- Mechanical Life: 500000 tested

- Black or White Color optional

- Recessed Intallation

- Suitable for access / entrance / automation

• Output Contact: NO\NC\COM
• Input: DC12V
• Surface installation, Black Color
• Standard Structure: scratch-resistant acrylic panel (can be loaded into a standard 86 bottom box)
• Mechanical Life: 500000 tested
• Trigger device: Touch
• Surface Intallation
• LED indicator status: white patterned light is off state
  LED Status: pattern light blue to standby
  LED Status: patterns of work status indicator is red
• Operating temp: 10~+55ºC(14-131F)
  Operating Humidity: 0-95% (non- condensing)
• Product Size:
  ZDBT-901:86Lx86Wx29H(mm)
  ZDBT-901B: 86Lx56Wx25H(mm)
• Packing size: 105*95*42mm; Weight: 0.1kg
