Motherboard | |
CPU |
Intel Bay Trail CPU Celeron quad core J1900 |
chipset |
CPU Integrated |
System Memory |
1x DDR3 SO-DIMM 4G up to 8GB |
Storage |
64G/128G SSD or 320G HDD /500G HDD |
LAN |
RealTek 8111E Gigabit Ethernet |
Audio |
RealTek ALC662 HD audio decode |
LCD touch panel | |
LCD size |
15 inch |
Touch screen |
Multiple-dot capacitive touch screen, USB interface |
Resolution |
1024*768 |
Brightness |
350cd /㎡ |
Response |
10ms |
Tilting Angle |
0-90 degrees |
External I/O ports | |
Serial ports |
1*DB9 (COM1,COM2) DC5V/12V jumper optional on PIN1 |
USB |
1*USB3.0 ,3 *USB 2.0 |
Ethernet |
1*RJ45 10/100/1000Mbps |
VGA |
1*DB15 2nd display VGA connector |
Audio |
1*line out 1*Mic in |
DC port |
1*12V/5A DC input for pos power source |
