Product code

L009UiGS-2HaxD-IN

Architecture

ARM

CPU

IPQ-5018

CPU core count

2

CPU nominal frequency

800 MHz

Switch chip model

88E6190

RouterOS license

5

Operating System

RouterOS v7

Size of RAM

512 MB

Storage size

128 MB

Storage type

NAND

MTBF

Approximately 200'000 hours at 25C

Tested ambient temperature

-40°C to 70°C

Suggested price

$129.00

Wireless 2.4 GHz Max data rate

574 Mbit/s

Wireless 2.4 GHz number of chains

2

Wireless 2.4 GHz standards

802.11b/g/n/ax

Antenna gain dBi for 2.4 GHz

4

Wireless 2.4 GHz chip model

IPQ-5018

Wireless 2.4 GHz generation

Wi-Fi 6

WiFi speed

AX600

10/100/1000 Ethernet ports

8

Number of 1G Ethernet ports with PoE-out

1

SFP ports

1 (2.5G supported)

Serial console port

RJ45

Number of USB ports

1

USB Power Reset

Yes

USB slot type

USB 3.0 type A

Max USB current (A)

1.5

Number of DC inputs

2 (DC jack, PoE-IN)

DC jack input Voltage

24-56 V

Max power consumption

47 W

Max power consumption without attachments

14 W

Cooling type

Passive

PoE in

802.3af/at

PoE in input Voltage

24-56 V

PoE-out ports

Ether8

PoE out

Passive PoE

Max out per port output (input 18-30 V)

1 A

Max out per port output (input 30-57 V)

450 mA

Max total out (A)

1.0 A

Certification

CE, FCC, IC, EAC, ROHS

IP

20

Mode button

Yes

1MBit/s

27

-100

11MBit/s

27

-94

6MBit/s

30

-96

54MBit/s

28

-80

MCS0

30

-96

MCS7

27

-75

MCS9

25

-70

MCS11

23

-67
