Specifications
|
Details | |
|
Product code |
D53G-5HacD2HnD-TC&RG502Q-EA |
|
Architecture |
ARM 32bit |
|
CPU |
IPQ-4019 |
|
CPU core count |
4 |
|
CPU nominal frequency |
716 MHz |
|
Switch chip model |
IPQ-4019 |
|
Dimensions |
240 x 156 x 44 mm |
|
RouterOS license |
4 |
|
Operating System |
RouterOS (v7 only) |
|
Size of RAM |
256 MB |
|
Storage size |
16 MB |
|
Storage type |
FLASH |
|
MTBF |
Approximately 200'000 hours at 25C |
|
Tested ambient temperature |
-40°C to 70°C |
|
IPsec hardware acceleration |
Yes |
|
Suggested price |
$530.00 |
Powering
|
Details | |
|
Number of DC inputs |
1 (DC jack) |
|
DC jack input Voltage |
12-28 V |
|
Max power consumption |
23 W |
|
Max power consumption without attachments |
17 W |
|
Cooling type |
Passive |
Mobile
|
Details | |
|
3G Category |
R8 (42.2Mbps Downlink, 5.76Mbps Uplink) |
|
3G bands |
6 (850 MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) / 19 (800 MHz) / 1 (2100MHz) |
|
LTE Category |
20 (2.0 Gbps Downlink, 200 Mbps Uplink) |
|
LTE FDD bands |
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 18 (800 MHz) / 19 (800 MHz) / 20 (800MHz) / 26 (850MHz) / 28 (700MHz) / 32 (1500 MHz) |
|
LTE TDD bands |
38 (2600MHz) / 39 (1900MHz) / 40 (2300MHz) / 41 (2500MHz) / 42 (3500MHz) / 43 (3700MHz) / 34 (2000 MHz) |
|
5G NSA FDD bands |
1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) / 28 (700 MHz) |
|
5G NSA TDD bands |
40 (2300 MHz) / 41 (2500 MHz) / 77 (3700 MHz) / 78 (3500 MHz) / 79 (4700 MHz) / 38 (2600 MHz) |
|
5G SA FDD bands |
1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) / 28 (700 MHz) |
|
5G SA TDD bands |
41 (2500 MHz) / 77 (3700 MHz) / 78 (3500 MHz) / 79 (4700 MHz) / 38 (2600 MHz) / 40 (2300 MHz) |
|
TAC |
86073604 |
Wireless specifications
|
Details | |
|
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
|
Wireless 2.4 GHz number of chains |
2 |
|
Wireless 2.4 GHz standards |
802.11b/g/n |
|
Antenna gain dBi for 2.4 GHz |
2 |
|
Wireless 2.4 GHz chip model |
IPQ-4019 |
|
Wireless 2.4 GHz generation |
Wi-Fi 4 |
|
Wireless 5 GHz Max data rate |
867 Mbit/s |
|
Wireless 5 GHz number of chains |
2 |
|
Wireless 5 GHz standards |
802.11a/n/ac |
|
Antenna gain dBi for 5 GHz |
4 |
|
Wireless 5 GHz chip model |
IPQ-4019 |
|
Wireless 5 GHz generation |
Wi-Fi 5 |
Ethernet
|
Details | |
|
10/100/1000 Ethernet ports |
5 |
Peripherals
|
Details | |
|
Number of SIM slots |
1 Modem (Micro SIM) |
|
Number of USB ports |
1 |
|
USB Power Reset |
Yes |
|
USB slot type |
USB type A |
|
Max USB current (A) |
1 |
|
Number of M.2 slots |
1 |
Other
|
Details | |
|
Mode button |
Yes |
Certification & Approvals
|
Details | |
|
Certification |
CE, EAC, ROHS |
Wireless specifications
|
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
|
1MBit/s |
25 |
-100 |
|
11MBit/s |
25 |
-94 |
|
6MBit/s |
26 |
-96 |
|
54MBit/s |
23 |
-78 |
|
MCS0 |
26 |
-96 |
|
MCS7 |
22 |
-73 |
|
5 GHz |
Transmit (dBm) |
Receive Sensitivity |
|
6MBit/s |
26 |
-96 |
|
54MBit/s |
22 |
-80 |
|
MCS0 |
26 |
-96 |
|
MCS7 |
21 |
-75 |
|
MCS9 |
19 |
-70 |
