System

Main Processor

Hi3521A

Operation System

LINUX, Compression Mode: H.264

Video

Video Input

16CH BNC

Video Output

1 x VGA / 1 x HDMI (1920*1080)

Video Distance

75-3 Cable up to 500 Meters / Video No Decay and Distortion

Audio

Audio Input

2CH RCA

Audio Output

1CH RCA

Recording

Recording Channel

16CH × 1080N;1080N at 12 Fps(NTSC),12 Fps(PAL)

Reolution

1080N: 1920 × 1080

Frame Rate

12 Fps(NTSC), 12 Fps(PAL)

Recording Mode

Realtime Video Recording

Playback

Playback Channel

16CH x 1080N at 12 Fps(NTSC), 12 Fps(PAL)

Playback Mode

Normal Play, Fast Forward, Frame by Frame, Zoom In / Out

Search Mode

Time, Date, Motion Detection, Exact Search

Alarm

Alarm Input

N/A

Alarm Output

N/A

Storage

HDD Interface

1 x SATA Fixed HDD(Up to 6TB)

Backup

USB Disk

2 x USB 2.0 port

Backup Format

H.264 (only for Playback Software - General H.264 Player V1.7.0.)

Backup Mode

Network download / Flash USB / movable HDD/SATA HDD / DVD-RW

PTZ

PTZ

R485 control

Network

Interface

RJ45 port / 10M / 100M / 1,000Mbps Ethernet

Protocol

TCP/IP, DHCP, DDNS, PPPoE, UPNP, NTP, SMTP, FTP, RTSP, ARSP

Mobile phone Support

mobile view app XMeye (iPhone, Android)

Computer System Support

Windows 2000, XP, Vista, 7, 8 / Mac OS x 10.6/10.7

Compatible Browser

iCloud Software, one-click online; Support IE, Firefox, Google Chrome

Free DDNS

iCloud Free DDNS Server (P2P function)

IP Camera Protocol

ONVIF Version Platform Protocol (Digital Menu)

Simultaneous Remote Viewers

6 Users Online

Others

Operating Temperature

0°C ~ 55°C

Operating Humidity

10% ~ 90%

Dimension

430mm× 300mm× 70mm

Weight

3.5 KG/(2 SATA 4KG)

HDD Screw

4 PCS (1 Pack)

Accessories

USB Mouse ×1PC/User Manual ×1PC/Power Supply × 1PC

Power Supply

DC12V/3A
