Details | |
Product code |
C52iG-5HaxD2HaxD-TC |
Architecture |
ARM 64bit |
CPU |
IPQ-6010 |
CPU core count |
4 |
CPU nominal frequency |
864 MHz |
Switch chip model |
IPQ-6010 |
RouterOS license |
4 |
Operating System |
RouterOS (v7 only) |
Size of RAM |
1 GB |
Storage size |
128 MB |
Storage type |
NAND |
MTBF |
Approximately 100'000 hours at 25C |
Tested ambient temperature |
-40°C to 50°C |
IPsec hardware acceleration |
Yes |
Suggested price |
$99.00 |
Details | |
Wireless 5 GHz Max data rate |
1200 Mbit/s |
Wireless 5 GHz number of chains |
2 |
Wireless 5 GHz standards |
802.11a/n/ac/ax |
Antenna gain dBi for 5 GHz |
4 |
Wireless 5 GHz chip model |
QCN-5052 |
Wireless 5 GHz generation |
Wi-Fi 6 |
Wireless 2.4 GHz Max data rate |
574 Mbit/s |
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz standards |
802.11b/g/n/ax |
Antenna gain dBi for 2.4 GHz |
4.5 |
Wireless 2.4 GHz chip model |
QCN-5022 |
Wireless 2.4 GHz generation |
Wi-Fi 6 |
WiFi speed |
AX1800 |
Details | |
10/100/1000 Ethernet ports |
5 |
Number of 1G Ethernet ports with PoE-out |
1 |
Details | |
Number of DC inputs |
2 (DC jack, PoE-IN) |
DC jack input Voltage |
12-28 V |
Max power consumption |
27 W |
Max power consumption without attachments |
12 W |
Cooling type |
Passive |
PoE in |
Passive PoE |
PoE in input Voltage |
18-28 V |
Details | |
PoE-out ports |
Ether 1 |
PoE out |
Passive PoE |
Max out per port output (input 18-30 V) |
600 mA |
Max total out (A) |
0.6 A |
Total output current |
0.6 |
Total output power |
16.8W |
Details | |
Certification |
CE, FCC, IC, EAC, ROHS |
IP |
20 |
Details | |
CPU temperature monitor |
Yes |
Mode button |
Yes |
