Specifications
|
Details | |
|
Product code |
C53UiG+5HPaxD2HPaxD |
|
Architecture |
ARM 64bit |
|
CPU |
IPQ-6010 |
|
CPU core count |
4 |
|
CPU nominal frequency |
auto (864 - 1800) MHz |
|
Switch chip model |
IPQ-6010 |
|
RouterOS license |
6 |
|
Operating System |
RouterOS v7 |
|
Size of RAM |
1 GB |
|
Storage size |
128 MB |
|
Storage type |
NAND |
|
MTBF |
Approximately 200'000 hours at 25C |
|
Tested ambient temperature |
-40°C to 70°C |
|
IPsec hardware acceleration |
Yes |
|
Suggested price |
$139.00 |
Wireless capabilities
|
Details | |
|
Wireless 2.4 GHz Max data rate |
574 Mbit/s |
|
Wireless 2.4 GHz number of chains |
2 |
|
Wireless 2.4 GHz standards |
802.11b/g/n/ax |
|
Antenna gain dBi for 2.4 GHz |
3.3 |
|
Wireless 2.4 GHz chip model |
QCN-5022 |
|
Wireless 2.4 GHz generation |
Wi-Fi 6 |
|
Wireless 5 GHz Max data rate |
1200 Mbit/s |
|
Wireless 5 GHz number of chains |
2 |
|
Wireless 5 GHz standards |
802.11a/n/ac/ax |
|
Antenna gain dBi for 5 GHz |
5.5 |
|
Wireless 5 GHz chip model |
QCN-5052 |
|
Wireless 5 GHz generation |
Wi-Fi 6 |
|
WiFi speed |
AX1800 |
Ethernet
|
Details | |
|
10/100/1000 Ethernet ports |
4 |
|
Number of 1G Ethernet ports with PoE-out |
1 |
|
Number of 2.5G Ethernet ports |
1 |
Peripherals
|
Details | |
|
Number of USB ports |
1 |
|
USB Power Reset |
Yes |
|
USB slot type |
USB 3.0 type A |
|
Max USB current (A) |
1 |
Powering
|
Details | |
|
Number of DC inputs |
2 (DC jack, PoE-IN) |
|
DC jack input Voltage |
12-28 V |
|
Max power consumption |
38 W |
|
Max power consumption without attachments |
15 W |
|
Cooling type |
Passive |
|
PoE in |
Passive PoE |
|
PoE in input Voltage |
18-28 V |
PoE-out
|
Details | |
|
PoE-out ports |
Ether 1 |
|
PoE out |
Passive PoE |
|
Max out per port output (input 18-30 V) |
0.625 A |
|
Max total out (A) |
0.625 A |
|
Total output current |
0.625 |
|
Total output power |
15 |
Certification & Approvals
|
Details | |
|
Certification |
CE, FCC, IC, EAC, ROHS |
Other
|
Details | |
|
CPU temperature monitor |
Yes |
|
Mode button |
Yes |
Wireless specifications
|
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
|
1MBit/s |
27 |
-100 |
|
11MBit/s |
27 |
-94 |
|
6MBit/s |
29 |
-96 |
|
54MBit/s |
27 |
-80 |
|
MCS0 |
29 |
-96 |
|
MCS7 |
26 |
-75 |
|
MCS9 |
24 |
-70 |
|
MCS11 |
22 |
-67 |
|
5 GHz |
Transmit (dBm) |
Receive Sensitivity |
|
6MBit/s |
28 |
-96 |
|
54MBit/s |
26 |
-80 |
|
MCS0 |
28 |
-96 |
|
MCS7 |
25 |
-75 |
|
MCS9 |
23 |
-70 |
|
MCS11 |
20 |
-67 |
