Lead time

Usually in Stock

provided equipment

User manual

Number of power module free slots

0

Number of power module filled slots

0

redundant

No

UPS size

WS

cable length

1.50 m

colour

Black

depth

30.5 cm

height

9.25 cm

mounting preference

No preference

net weight

5.7 kg

mounting mode

Not rack-mountable

two post mountable

0

USB compatible

No

width

16.05 cm

network frequency

50/60 Hz +/- 5 Hz auto-sensing

plug standard

Schuko CEE 7/7P

input voltage limits

170...280 V

number of cables

1

input voltage

230 V

rated power in W

600 W

Maximum configurable power in W

600 W

output frequency

50/60 Hz +/- 1 Hz unsynchronised

UPS type

Line interactive

Wave type

Stepped approximation to a sinewave

nb of power socket outlets

4 Schuko CEE 7

curve equation

Efficiency

curve fixed loss

0.0232

curve load maximum

100 %

curve load minimum

3 %

curve proportional loss

0

curve square loss

0.0035

curve X-axis maximum

100 %

curve test cond ID

Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 230V/50Hz electrical input and balanced resistive load (PF =

curve X-axis minimum

0 %

curve X-axis title

Load

curve X-axis units

Percentage

curve Y-axis maximum

100 %

curve Y-axis minimum

50 %

curve Y-axis title

Efficiency

curve Y-axis units

Percentage

graph display

1

output voltage

230 V

Maximum configurable power in VA

1000 VA

rated power in VA

1000 VA

Transfer time

6 ms typical : 10 ms maximum

product certifications

CE

standards

EN/IEC 62040-1
EN/IEC 62040-2

ambient air temperature for operation

0…40 °C

relative humidity

0…90 %

operating altitude

0...6667 ft

ambient air temperature for storage

-20…50 °C

Storage Relative Humidity

0…90 %

storage altitude

0.00…15240.00 m

acoustic level

40 dBA

show note OP temperature

No

IP degree of protection

IP20

battery type

Lead-acid battery

number of battery filled slots

0

number of battery free slots

0

Battery recharge time

8 h

liquid value

0

battery voltage

12 V

battery capacity

9.0 Ah

battery curve

B

battery life

3…5 year(s)

extended runtime

0

control panel

LED Status display with on line : on battery

alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge energy rate

156 J

Package 1 Weight

6 kg

Package 1 Height

23.7 cm

Package 1 width

14.3 cm

Package 1 Length

37.3 cm

SCC14

10731304338243

Sustainable offer status

Green Premium product

REACh Regulation

REACh Declaration

EU RoHS Directive

Compliant
EU RoHS Declaration

Mercury free

Yes

RoHS exemption information

Yes

Environmental Disclosure

Product Environmental Profile

Circularity Profile

End of Life Information

Optimized Energy Efficiency

Energy efficient product

Warranty

2 years repair or replace
