Plug Type

EU, UK, US

Standards and Protocols

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Interface

1 * 10/100Mbps Ethernet Port (RJ45)

Button

RE (Range Extender) Button, Reset Button

Power Consumption

About 3W

Dimensions ( W x D x H )

4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm)

Antenna

2 * external

Frequency

2.4~2.4835GHz

Signal Rate

11n: Up to 300Mbps (dynamic)
11g: Up to 54Mbps (dynamic)
11b: Up to 11Mbps (dynamic)

Reception Sensitivity

270M: -69dBm@10% PER
130M: -69dBm@10% PER
108M: -69dBm@10% PER
54M: -69dBm@10% PER
11M: -86Bm@8% PER
6M: -89dBm@10% PER
1M: -91dBm@8% PER

Transmit Power

< 20 dBm (EIRP)

Wireless Modes

Range Extender

Wireless Functions

WMM (Wi-Fi Multimedia)
Wireless MAC Address Filtering
Wireless Statistic
Domain Login Function

Wireless Security

64/128/152-bit WEP
WPA-PSK / WPA2-PSK

Certification

RoHS

Package Contents

300Mbps Wi-Fi Range Extender with AC Passthrough TL-WA860RE
RJ-45 Ethernet Cable
Quick Installation Guide

System Requirements

Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
